| CPU |
- LGA1151 socket 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processor (CPU TDP max. up to 35 W)
|
| Chipset |
|
| System Memory |
- 6th gen: 2 x 260-pin SO-DIMM DDR4-1866/2133, up to 32GB
- 7th gen: 2 x 260-pin SO-DIMM DDR4-2133/2400, up to 32GB
|
| BIOS |
|
| COM |
- 2 x RS-232/422/485 (onboard)
- 2 x RS-232/422/485 (via cable on flexible IO window)
|
| USB |
|
| Ethernet/PoE |
- 4 x 10/100/1000 Mbps (Intel® i210-IT, i219-LM)
|
| Display |
- 2 x HDMI (1 x HDMI 2.0 & 1 x HDMI 1.4b)
- 1 x DisplayPort
|
| Digital I/O |
- 32-channel programmable DI/DO
|
| Audio |
- 1 x Audio (Mic-in/Line-out)
|
| Storage |
- 2 x 2.5” SATA HDD drive bay (max. up 15 mm height & RAID 0 & 1)
- 1 x CFast™
- 1 x mSATA (enabled in BIOS setting)
|
| Expansion |
- 2 x Full-size PCI Express Mini Card (USB + PCI Express signal)
- 1 x SIM slot
|
| Others |
- 1 x Flexible I/O window (default : 2 x COM port)
- 4 x SMA type connector opening for antenna
- 1 x Phoenix type VDC power input connector
- 1 x ATX power switch
- 1 x Remote power switch
- 1 x AT/ATX quick switch
- 1 x Reset button
|
| Power |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Construction |
- Aluminum extrusion and heavy-duty steel, IP40
|
| Operating Temperature |
- -40°C to +60°C (-40°F to +140°F) (with W.T. DRAM/SSD for Skylake)
- -40°C to +55°C (-40°F to +131°F) (with W.T. DRAM/SSD for Kaby Lake)
|
| Relative Humidity |
- 10% - 95%, non-condensing
|
| Shock |
|
| Vibration |
- 3 Grms with SSD (5 to 500 Hz, X, Y, Z directions)
|
Dimensions
(W x D x H) |
- 280 x 190 x 76 mm (11.02” x 7.48” x 2.99”)
|
| Weight (net/gross) |
- 3.8 kg (8.37 lb)/ 4.6 kg (10.14 lb)
|
| Certifications |
- UL62368-1, CE, FCC Class A
|
| EOS Support |
|
| Software Support |
|
| Mounting |
|
