CPU |
- Intel® Core™ i5-7300U 2.6 GHz
- Intel® Celeron® 3965U 2.2 GHz
|
Chipset |
|
System Memory |
- 1 x 260-pin DDR4-2133 SO-DIMM, up to 16GB
|
BIOS |
|
COM |
|
USB |
|
Ethernet/PoE |
- 2 x 10/100/1000 Mbps Ethernet (Intel® I219-LM, Intel® I210-AT)
|
Display |
|
Digital I/O |
|
Audio |
|
Storage |
- 1 x M.2 Key B 2242 (for SATA storage)
|
Expansion |
- 1 x M.2 Key E 2230 (for Wi-Fi)
|
Others |
- 1 x ATX power switch
- 1 x AT/ATX quick switch
- 1 x Screw type VDC power input connector
- 2 x Antenna opening
|
Power |
|
Watchdog Timer |
- 65535 levels, 1 to 65536 sec.
|
Construction |
- Aluminum extrusion and heavy-duty steel, IP40
|
Operating Temperature |
- -10°C to +50°C (+14°F to +122°F) (with W.T. SSD/DRAM)
|
Relative Humidity |
- 10% - 90%, non-condensing
|
Shock |
- IEC 60068-2-27 (with SSD: 50G, half sine, 11 ms duration)
|
Vibration |
- IEC 60068-2-64 (with SSD: 3Grms STD, random, 5 to 500 Hz,1 hr/axis)
|
Dimensions (W x D x H) |
- 142 x 87 x 58 mm (5.59" x 3.42" x 2.28")
|
Weight (net/gross) |
- 0.6 kg (1.32 lb)/1.5 kg (3.3 lb)
|
Certifications |
- CE, FCC Class A, UKCA and IEC60945
|
EOS Support |
|
Software Support |
|
Mounting |
- Wall mount kit
- Din-rail kit
- VESA mount Kit
|
