| CPU |
- Intel® Xeon® D-1712TR (4 x 2.0 GHz, 10MB cache, 50G Eth, 40W)
- Intel® Xeon® D-1715TER (4 x 2.4 GHz, 10MB cache, 50G Eth, 50W)
- Intel® Xeon® D-1732TE (8 x 1.9 GHz, 15MB cache, 50G Eth, 52W)
- Intel® Xeon® D-1735TR (8 x 2.2 GHz, 15MB cache, 50G Eth, 59W)
- Intel® Xeon® D-1746TER (10 x 2.0 GHz, 15MB cache, 100G Eth, 67W)
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-2400 SO-DIMM, up to 64GB with ECC support
|
| BIOS |
|
| Serial |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000/2500 Mbps with Intel® I226, configured through COMe PCIe port 7
- 4 x 10GBASE-KR with Intel® 10G external PHY
|
| Display |
|
| GPIO |
|
| Audio |
|
| Storage |
|
| Expansion |
- 1 x PCIe x16 Gen3 (PEG)
- 1 x PCIe x8 Gen3
- 6 x PCIe x1 Gen3
|
| Others |
- TPM 2.0
- 1 x I2C
- 1 x LPC
- 1 x SPI
|
| Battery |
|
| Power Input |
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Standard: 0°C to +60°C (+32°F to +140°F)
- Extended: -40°C to +85°C (-40°F to +185°F) with system thermal solution
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
