| CPU |
- LGA1700 socket 13th/12th Gen Intel® Core™ i7/i5/i3 processor (max. 35W TDP)
|
| Chipset |
|
| System Memory |
- 2 x DDR4-3200 SO-DIMM, up to 64GB (DDR5 version will be available in Q1 2026)
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| COM |
|
| USB |
- 2 x USB 3.2 Gen 2
- 2 x USB 3.2 Gen 1
- 8 x USB 2.0
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet
|
| Display |
- 1 x HDMI 2.0, 4K display
- 1 x DisplayPort 1.4, 4K display
|
| Audio |
|
| Storage |
- 1 x SATA 3.0 (6Gb/s)
- 1 x M.2 Key M 2242/2280 (PCIe x4 Gen 3 interface)
|
| Expansion |
- 1 x M.2 Key E 2230 slot for Wi-Fi (USB 2.0 + PCIe signal)
|
| Others |
- 1 x Power switch
- 1 x 4-pin DC-in
- 1 x Remote power switch
- 1 x Reset switch connector
|
| TPM |
|
| Power Supply |
|
| Vibration Endurance |
|
| Operating Temperature |
- 0°C to +50°C (+32°F to +122°F)
|
| Dimensions (W x D x H) |
- 215 x 200 x 72 mm (8.46" x 7.87" x 2.83")
|
| Weight (net/gross) |
- 1.8 kg (3.96 Ib)/2.8 kg (6.17 Ib)
|
| Mounting |
|
| EOS Support |
|
| Software Support |
|
| Certifications |
|
