| CPU |
- Intel® Processor N97/N150
|
| Chipset |
|
| System Memory |
- 1 × 262-pin DDR5-4800 SO-DIMM, up to 32GB
|
| BIOS |
|
| COM |
- 2 × RS-232 (wafer) (default: RS-232/jumper-selectable RS-422 or RS-485)
- 4 × RS-232 (wafer)
|
| USB |
- 3 × USB 3.2 Gen 1 (rear, 1 port co-layout with M.2 Key B)
- 1 x USB Type-C (DisplayPort/USB 5 Gbps support)
- 2 × USB 2.0
|
| Ethernet |
- 1 × 2.5GbE Ethernet (RTL8125BG-CG)
- 1 × GbE Ethernet (RTL8111H-CG)
|
| Display |
- 1 × HDMI
- 1 x VGA
- 1 × LVDS (co-layout with eDP)
|
| Digital I/O |
|
| Audio |
|
| Storage |
- 1 x M.2 Key M 2280 (SATA/NVMe auto detect)
- 1 x SATA 3.0
|
| Expansion |
- 1 x M.2 Key E 2230 (PCIe 3.0 x1, USB 2.0)
- 1 x M.2 Key B 3042/3052 (PCIe 3.0 x1 + USB 3.2 Gen 1 + USB 2.0)
- 1 x Nano SIM
|
| Others |
- TPM 2.0 supported by Intel® Platform Trust Technology (PTT)
- GPIO 8-bit (2.54 mm pitch)
|
| Battery |
|
| Power Input |
- 12V to 24V DC in, ATX mode (jumper-selectable AT mode)
- (ATX 2 × 2-pin connector supported by BOM selection)
|
| Watchdog Timer |
- 255 levels, 0 to 255 sec.
|
| Hardware Monitoring |
- Detect CPU/system temperature, voltage, and fan speed
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 5% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
