| CPU |
- Intel® Pentium® processor N4200 & Celeron® processor N3350 onboard
|
| Chipset |
|
| System Memory |
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® I210)
|
| Display |
- 1 x DDI (DisplayPort, HDMI, DVI)
- 1 x LVDS (eDP optional)
|
| Audio |
- HD link interface to baseboard for Codec
|
| GPIO |
|
| I2C |
|
| CAN |
|
| SPI |
|
| Storage |
- eMMC 5.0 up to 64GB (optional)
- 2 x SATA-600
|
| Expansion |
- 4 x PCIe x1 (3 x PCIe x1 if onboard LAN is supported)
|
| Others |
- 1 x LPC interface (optional)
- 1 x SDIO
- SMBus
- Smart Battery
|
| Battery |
|
| Power Requirement |
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- -20°C to +70°C (-4°F to +158°F)
|
| Relative Humidity |
- 10% - 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
