| LCD Panel |
- 15" XGA TFT LCD with LED backlight
- 450 nits
- 1024 x 768
|
| CPU |
- Intel® Celeron® processor N3060 (up to 2.48 GHz)
|
| Chipset |
|
| System Memory |
- 1 x 204-pin SO-DIMM DDR3L-1600, up to 8GB
|
| BIOS |
|
| COM |
- 1 x RS-232
- 1 x RS-232/422/485
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000 Mbps (Intel® I210-AT)
|
| Display |
|
| Audio |
|
| Storage |
- 1 x 2.5" SATA HDD (9.5 mm)
- 1 x mSATA
|
| Expansion |
- 1 x Full-size PCI Express Mini Card with mSATA supported
- 1 x Full-size PCI Express Mini Card with SIM slot
|
| Others |
- 1 x 8-bit DIO port (programmable, DB9)
- 1 x switch for power on/off
- 1 x AT/ATX mode selection switch
|
| Touchscreen |
|
| Front Bezel |
- IP65, NEMA 4 rugged protection, plastic front bezel
|
| Power Supply |
- DC version: 24 VDC overcurrent protection fuse
- AC version: 100 - 240V AC-DC, 60W power adapter
|
| Power Comsumption |
|
| Watchdog Timer |
|
| Operating Temperature |
- 0°C to +50°C (+32°F to +122°F)
|
| Relative Humidity |
- 20% - 90% @ +40°C; non-condensing
|
| Vibration |
- 2G, 10 - 500Hz, random for SSD
|
Dimensions
(W x D x H) |
- 387.9 x 54.6 x 307.7 mm (15.27" x 2.14" x 12.11")
|
| Weight (net/gross) |
- 3.2 kg (7.05 lb)/5.1 kg (11.24 lb)
|
| Certifications |
|
| EOS |
- WES 7, Windows® 7, WE8S (64-bit), Windows® 8.1 (64-bit), Windows® 10
|
| Mounting |
- Panel mount
- Wall mount
- VESA arm
- Desktop stand
|
