| CPU |
- FCLGA1200 10th gen Intel® Core™ i9/i7/i5/i3, Intel® Pentium® processors Gold/Celeron® processors (up to 65W)
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-2933/2666/2400 SO-DIMM, up to 64GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 (with +5V/+12V power)
- 1 x RS-232
|
| USB |
- 2 x USB 3.2 Gen1
- 5 x USB 2.0
|
| Ethernet |
- 1 x 10/100/1000 Mbps Ethernet with Intel® i211-AT; supports Wake-on-LAN, PXE Boot ROM
- 1 x 10/100/1000 Mbps Ethernet with Intel® i219-V; supports Wake-on-LAN, PXE Boot ROM
|
| Display |
- 1 x DisplayPort++
- 1 x HDMI 2.0
- 1 x eDP
- 1 x VGA
|
| Digital I/O |
- 8-channel in/out programmed
|
| Audio |
|
| Storage |
- 1 x M.2 Key B 2242/2280
- 2 x SATA-600
|
| Expansion |
- 1 x PCIe x16
- 1 x M.2 Key B 3042/3052 for 5G module (USB 3.2 Gen1)
- 1 x M.2 Key E 2230
- 1 x PCIe Mini Card slot
|
| Others |
- Onboard TPM 2.0 (optional)
|
| Battery |
|
| Power Input |
- Standard 12V ATX power
- 24+4 pin ATX connector
- AT Mode Auto Power Function supported
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
