| CPU |
- 13th/12th Gen Intel® Core™ processor (U series)
|
| Chipset |
|
| System Memory |
- 2 x Dual-channel DDR4-3200 SO-DIMM slot, up to 64GB
|
| BIOS |
|
| Serial |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000/2500 Mbps Ethernet (Intel® I226)
|
| Display |
- 1 x LVDS; 18/24-bit single/dual channel (optional eDP 1.4b HBR3: 5120 x 3200 @ 60Hz)
- 1 x VGA; 1920 x 1200 @ 60Hz (default)
- 2 x Display type (with up to 4K supported)
|
| GPIO |
|
| Audio |
- HD link interface to baseboard for Codec
|
| Storage |
- 2 x SATA 3.0
- NVMe for up to 512GB (optional)
|
| Expansion |
- 1 x PCIe x4 Gen4 (PEG) + 5 x PCIe Gen3 (Default)
- 1 x PCIe x4 Gen4 (PEG) + 8 x PCIe Gen3 (by request)
|
| Others |
|
| Battery |
|
| Power Input |
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Standard: 0°C to +60°C (-40°F to +140°F)
- Extended Temperature: -40°C to +85°C (-40°F to +185°F)
|
| Relative Humidity |
- 10% - 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
