| LCD Panel |
- 15" XGA TFT LCD
- 300 nits
- 1024 x 768 pixels
|
| CPU |
- LGA1700 socket 12th gen Intel® Core™ i7/i5/i3, Celeron® & Pentium® processor (Tj 100°C) TDP 35W/65W
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-3200/2666/2400MHz SO-DIMM, up to 64GB
|
| BIOS |
|
| COM |
- 1 x RS-232
- 1 x RS-232/422/485
|
| USB |
- 2 x USB 3.2 GEN1
- 4 x USB 2.0
|
| Ethernet |
- 1 x 2500/1000/100/10Mbps Ethernet (Intel® I225-V )
- 1 x 1000/100/10Mbps Ethernet (Intel® I219-V)
|
| Display |
- 1 x HDMI
- 1 x VGA
- 1 x DisplayPort
|
| Audio |
- 1 x Audio (Mic-in & Line-out)
|
| Storage |
- 1 x 2.5” SATA HDD(WT)/SSD
|
| Expansion |
- 1 x Flexible IO window (optional)
- 1 x PCIe x16
|
| Others |
- 1 x Remote power switch
- 1 x AC socket
- TPM 2.0
|
| Touchscreen |
|
| Front Bezel |
- Aluminum w/ IP65/NEMA 4 rugged protection
|
| Power Supply |
|
| Power Comsumption |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Operating Temperature |
- 0°C to +50°C (+32°F to +122°F)
|
| Relative Humidity |
- 10% to 90% @ +40°C, non-considering
|
| Vibration |
- 1G, 5 - 500Hz, operation (SSD, random)
|
Dimensions
(W x D x H) |
- 378.3 x 88.8 x 310.3 mm (14.89" x 3.5" x 12.22")
|
| Weight (net/gross) |
- 6.3kg (13.89lb)/ 8.6kg (18.96lb)
|
| Certifications |
- CE, EN 61000-6-2, EN 61000-6-4
- UKCA
- FCC Class A
|
| EOS |
|
| Mounting |
|
