| CPU |
- LGA1700 12th gen Intel® Core™ i7/i5/i3 or Celeron® processor (TDP up to 35W)
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-3200/2666/2400 SO-DIMM, up to 64GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 (COM1)
- 3 x RS-232 (COM2-4)
|
| USB |
- 2 x USB 3.2 Gen1
- 2 x USB 2.0
|
| Ethernet/PoE |
- 1 x 2500/1000/100/10 Mbps Ethernet (Intel® I225-V)
- 1 x 1000/100/10 Mbps Ethernet (Intel® I219-V)
|
| Display |
|
| Digital I/O |
- 1 x 8-CH DIO (4-in/4-out)
|
| Audio |
|
| Storage |
- 1 x 2.5" SATA HDD drive bay (up to 15 mm height)
|
| Expansion |
- 1 x M.2 Key B 2242 (PCIe x2 signal; for storage only)
- 1 x M.2 Key E 2230 (PCIe x1 & USB 2.0 signal)
- 1 x Full-size PCI Express Mini Card slot (PCIe x1 & USB 2.0 signal)
|
| Others |
|
| Power |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Construction |
- Aluminum extrusion and heavy-duty steel, IP40
|
| Operating Temperature |
- -10°C to +50°C (14°F to 122°F) (with W.T. SSD/DRAM)
|
| Relative Humidity |
- 10% - 90%, non-condensing
|
| Vibration |
- IEC 60068-2-64 (w/SSD: 3Grms STD, random, 5 - 500 Hz, 1 hr/axis)
|
| Shock |
- IEC 60068-2-27 (w/SSD: 50G, half sine, 11 ms duration)
|
Dimensions
(W x D x H) |
- 195 x 210.6 x 80 mm (7.67" x 8.27" x 3.14")
|
| Weight (net/gross) |
- 3 kg (6.61 lb)/3.6 kg (7.94 lb)
|
| Certifications |
|
| EOS Support |
- Win 10 IoT, Win 11 IoT, Linux
|
| Software Support |
|
| Mounting |
- Wall mount kit
- DIN-rail kit
|
