| CPU |
- LGA1700 socket 14th/13th/12th gen Intel® Core™ i9/i7/i5/i3 or Celeron® processor (up to 65W)
|
| Chipset |
- Intel® Q670E/R680E/H610E/H610
|
| System Memory |
- 2 x 260-pin DDR4-3200 SO-DIMM, up to 64GB (PCB: V.A)
- 2 x 262-pin DDR5-5600 SO-DIMM, up to 96GB (PCB: V.B)
|
| BIOS |
|
| COM |
- 4 x RS-232/422/485 (for DDR4 version)
- 2 x RS-232/422/485 and 2 x RS-232 (for DDR5 version)
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000/2500 Mbps Ethernet (Intel® I226-LM)
- 2 x 10/100/1000/2500 Mbps Ethernet (Intel® I226-V)
|
| Display |
- 1 x DisplayPort++ (This feature only supports all SKUs of V.A and the R680E SKU of V.B.)
- 1 x eDP
- 2 x HDMI
|
| Digital I/O |
- 8-channel in/out programmed
|
| Audio |
|
| Storage |
- 2 x SATA-600
- 1 x M.2 Key M 2280 with support of NVMe
|
| Expansion |
- 1 x PCIe x16
- 1 x M.2 Key E 2230
- 1 x M.2 Key B 3052/3042 (STD SKU only supports V.A of Q670E/R680E and V.B of R680E)
|
| Others |
|
| Battery |
|
| Power Input |
- 24+8-pin ATX connector
- Supports AT Mode Auto Power-on
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
