CPU |
- Freescale i.MX6 Quad/DualLite ARM Cortex™-A9 CPU 800 MHz (On Q7M120 SoM)
|
Chipset |
|
System Memory |
- Onboard DDR3-1600, up to 1GB (on Q7M120 SoM)
|
BIOS |
|
COM |
- 4 x COM with TX/RX/RTS/CTS (one with 3.3V TTL level)
- 1 x Console port
|
USB |
- 1 x USB 2.0
- 1 x OTG client
|
Ethernet |
- 1 x 10/100 Mbps
- 1 x 10/100/1000 Mbps
|
Display |
- 1 x HDMI 1080P
- 1 x Dual channel 24-bit LVDS
- 1 x 18/24-bit TTL LCD
|
Audio |
|
GPIO |
|
CAN |
|
I2C |
|
SPI |
|
Storage |
- 1 x SD/MMC socket
- 1 x SATA connector
|
Expansion |
- 2 x Full size PCI Express Mini Card (with SIM)
|
Others |
- 8 x button-detect circuit
|
Battery |
- Battery on the Baseboard is required
|
Power Requirement |
|
Watchdog Timer |
|
Hardware Monitoring |
|
Operating Temperature |
|
Relative Humidity |
- 10% ~ 95%, non-condensing
|
Dimensions |
|
Board Thickness |
|
Certifications |
|
