| CPU |
- Intel® Celeron® processor J6412
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-3200/2666/2400 SO-DIMM, up to 32GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 and 4 x RS-232 (internal)
- 1 x RS-232/422/485 (rear I/O)
|
| USB |
- 4 x USB 2.0 (internal)
- 4 x USB 3.1 (rear I/O)
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Realtek RTL8111H)
|
| Display |
- 1 x HDMI 1.4b
- 1 x VGA
- 1 x LVDS (eDP BOM optional)
|
| Digital I/O |
- 8-channel in/out programmable
|
| Audio |
|
| Storage |
|
| Expansion |
- 1 x PCIe x4 slot with PCIe x2 signal
- 1 x M.2 Key B (USB 3.1 for 3042/3052 5G module or SATA interface for 2242 SSD)
- 1 x PCIe Mini Card slot
- 1 x SIM Card slot
|
| Others |
- Infenon SLB9760 T2.0 with TPM 2.0 compliant
- 1 x 1*5 SMBus pin header
|
| Battery |
|
| Power Input |
- 1 x 9 to 20V DC Jack
- 1 x 9 to 20V 4-pin ATX connector
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
