| CPU |
- Intel Atom® x6425RE/x6413E/x6414RE or Intel® Pentium® J6426
|
| Chipset |
|
| System Memory |
- 2 x Dual-channel DDR4-3200 SO-DIMM slot, up to 32GB
|
| BIOS |
|
| Serial |
|
| USB |
- 2 x USB 3.2 Gen1
- 8 x USB 2.0
|
| Ethernet |
- 1 x 10/100/1000/2500 Mbps Ethernet (Intel® I226)
|
| Display |
- 1 x LVDS (optional eDP 1.4b HBR3: 5120 x 3200@60Hz)
- 2 x DDI
|
| GPIO |
|
| Audio |
- HD link interface to baseboard for Codec
|
| Storage |
- 2 x SATA Gen3
- eMMC5.1, up to 64GB
|
| Expansion |
- 5 x PCIe x1
- 6 x PCIe x1 (optional, by removing 2.5GbE)
|
| Others |
|
| Battery |
|
| Power Input |
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Industrial: -40°C to +85°C (-40°F to +185°F)
- Standard: 0°C to +60°C (32°F to 140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
